采購：輕木板材2000方，聯系電話：13851609994

葉片輕木采購要求

1、  生產規格和技術要求：

Specification and technical requirement :

1.1巴沙木膠粘板材，規格如下：

Balsa Wood Glued Block, specs as below:

*長度：48?"±?"；寬度：24?"±?"；高度：6"-24"+1"；

Length:48?"±?"；Width:24?"±?"；Height:6"-24"+1"；

*條帶狀板材密度：112-250kg/m3；板材密度：90%135-190kg/m3,10%≤195kg/m3

Strip Density:112-250kg/m3；Block Density:90%135-190kg/m3,10%≤195kg/m3

*水分含量：<12％。

Moisture Content:<12%。

1.2 外觀要求：Appearance Requirements:

巴沙木板材中的木塊嚴禁在邊緣或邊角位置處出現任何形式的斷裂，嚴禁在寬度、高度和長度方向上存在超差現象，同時，不可接受任何形態的破損、斷裂或連結不良的木塊。不接受帶有蛾，昆蟲或腐爛木材的木塊。巴沙木板材帶有網格粘面的一側必須是完全平坦的。已經結晶化的膠體嚴禁出現在板材木塊中的任何一個平面。板材中間不允許有拼接。

Blocks must not present any crack on sides or corners above the width height and length tolerances, Damaged, broken or joint blocks will not be accepted. Blocks with moth, insects or rotten wood will not be accepted. One of the grid face of the blocks must be completely flat. Crystalized gluespread on any of the faces of the block is not allowed. The blocks must not have a joint in the middle.

1.3 每個集裝箱的木塊裝載數量：

Quantity of Blocks Load per Container:

*高度為12" -21"：不超過集裝箱容量的10％。

12" -21" Height: Not over than 10% of the Container.

*高度為24" -30"：不超過集裝箱容量的5％。

24" -30" Height: Not over than 5% of the Container.

*高度為39" -48"：不低于集裝箱容量的85％。

39" -48" Height: Not less than 85% of the Container.

Seller will issue a Quality Warranty Letter before the container is loaded，and saying the blocks that provided by seller are qualified and buyer can deduct value of disqualified blocks in the following payment after warehouse inspection.

The Quality Warranty Letter should be issued to BNBMG before the container is loaded.

在裝載集裝箱之前，應簽發質量保證書。

1.4  賣方應確保集裝箱滿載, 嚴禁將托盤放置于集裝箱中,每個集裝箱裝載的量不得少于26000BFT,溢裝數量和金額為+10%。

巴 薩 木 （ B l o c k ） 技 術 規 范 書

輕木技術規范 Specification Procurement Technology of Balsa Wood ? MAIN PRODUCT INFORMATION. 主要產品信息 ? Material Name: Glued Raft Balsa Blocks (Ochroma Pyramidale). 材質名稱:輕木粘合木 塊(巴爾薩木)。 ? Grade: Industrial grade. 等級：工業級 ? PHYSICAL PROPERTIES OF THE PRODUCT. 產品的物理屬性 ? Block density range. 木塊密度范圍。 ? 135 kg/m3 to 185 kg/m3. ? Slat density. 木板/條密度。 ? Minimum Density: 90 kg/m3. 最小密度: 90 kg/m3. ? Maximum Density: 254 kg/m3. 最大密度: 254 kg/m3 ? Tolerance: + 0 - 5 kg/m3. 公差: + 0 - 5 kg/m3 ? Blocks and slats with density outside tolerance will not be accepted. 不接受密度公 差以外的塊和板條。 ? Slat Thickness. 板條厚度 ? The slats should havea minimum thickness of height of 1" by 1" and a maximum of 6" in width. 板條必須至少具有 1" 乘 1" 的最小高度和最大 6" 寬度。 ? Material Moisture Content 材料水分含量 ? Minimum humidity content: 8%.最低水分含量: 8%. ? Maximum humidity content: 12%. 最高水分含量: 12%. 1

巴 薩 木 （ B l o c k ） 技 術 規 范 書 2 Note: Moisture control as low as possible. Templates per block 塊的模板 ? Block or slat joins are not allowed. 不允許塊或板條聯接。 ? Two thin templates cannot be together, the templates should always alternate thin and thick. 兩個精簡模板不能放在一起,模板應始終交替薄和厚。 ? List Defects Table – Blocks. Critical Defects 關鍵缺陷 Maximum Allowed Defects 允許的最大缺陷 By drying (Large cracks). Rot. Oil or grease None None None Other Defects 他缺陷 Maximum Allowed Defects 允許的最大缺陷 Heart of water. Heart (Marrow). Grained or soft cork. Loose knots. Worm holes. 2mm moth holes. Diameter Mineral stain and half bluish not associated with rot. Cracks or openings with a width not greater than 2mm. Depth not greater than 20mm. Solid knots diameter less than 1/2" and a distance of no more than 2" None. None None. None. None. 30% of the slat surface. Max. 10 slats per block scattered Max. 5 intermediate slats per block. 4 per block. ? MATERIAL SIZES AND DIMENSIONS. 規格尺寸 largo Width High Sizes Tolerance Sizes Tolerance Size Tolerance 12 3/4 - 48 3/4" + ? 24 3/4" + ?" 48 3/4 + ?"

巴 薩 木 （ B l o c k ） 技 術 規 范 書 3 ? APPEARANCE OF MATERIAL ? General ? No cracks in the corners. Part rotates only within width, length, and height tolerances. 木塊拐角處沒有裂縫，尺寸在寬度、長度和高度公差范圍內. ? No broken, articulated or damaged blocks. 1/4 difference between other woods. 沒有破損，粘接或損壞的木塊。 其他木材之間的差異為 1/4”. ? The wooden b-side of the block can accept a non-straight presentation only when the dimensions of the block are not affected by the length of the woods. 只有當木 塊的尺寸不受木材長度的影響時，木質 b 面才能接受非直線型. ? All sides a, b, c, d must be straight with a tolerance of no more than a depth of 1/4 compared to the other sides of the block. 所有側面 a，b，c，d 必須是直的，與塊 的其他側面相比，公差不超過 1/4”. ? GRAFT BLOCKS ? Pointed blocks with slats of minimum length 9", will be discounted 2" per block in the length of the block. 12" - 48"
